UNITY SLIM SMART LOCK 30BS 2PT ST - TIMBER RETROFIT BLACK

Yale Unity Slim Smart Lock

Introducing a keyless, secure, and user-friendly smart lock designed for all types of hinged doors. The Yale Unity Slim Smart Lock offers both keypad entry and seamless control through the Yale Home App on your smartphone. Installation is a breeze on slender or wide, timber or aluminium doors. Designed in New Zealand to withstand the harshest weather conditions, the Unity Slim Smart Lock uses the Induro® 2-Point lift-to-lock system. This updated version of the Induro® 2-Point lock is specifically designed for secure compatibility with the Unity® Slim Smart Lock escutcheon.

• Features 2 points of locking from the latch and deadbolt
• The handing of the lockset is adjusted by reversing the orientation of the latch bolt
• 30mm backset
• 85mm pitch
• Preset 13mm throw on deadbolt
• Suitable for 35mm to 60mm door thicknesses
• Stainless steel forend plate
• Adjustable latch projection
• Latch wear insert included
• Includes packers and alternate strikes
• Designed for aluminium joinery suites or timber joinery
• When used with the correct strike the lock generates optimum seal compression to provide improved water and air seal performance, especially for large panel doors
• Polyester powdercoated finish on furniture
• New Zealand designed

Owner's manual

User Guide

Flyer

Routing Template
